Bellwood Borough Authority Waterline Replacement Project
The Bellwood Borough Authority contracted Point Design Group to assist them in preparing plans and specifications, contract award administration and construction observation.
Improvements included two pump stations, influent metering, influent grinder, aeration and baffles for the lagoons, phosphorus removal tanks, tertiary filters and ultraviolet disinfection.
Point Design Group was hired by MWCD to evaluate alternatives to improve its lagoon WWTP that discharges into Seneca Lake. After acceptance of the evaluation, we designed improvements which were needed to meet discharge requirements by the Ohio EPA. Improvements included two pump stations, influent metering, influent grinder, aeration and baffles for the lagoons, phosphorus removal tanks, tertiary filters and ultraviolet disinfection.
Project Client:
MWCD
Project Location:
Guernsey- Watershed Conservancy District
Services Included:
Evaluation of WWTP Alternatives
WWTP and Sewer Design
Governmental Permit Applications
Construction Administration Services
Topographic Survey and Base Mapping
Technical Specifications and Bidding/Contract Documents
Bidding Services
The Bellwood Borough Authority contracted Point Design Group to assist them in preparing plans and specifications, contract award administration and construction observation.
Penn Trafford School District requested Point Design Group to assist with preparing plans and specifications and contract award administration for pipe bursting sections of badly broken sanitary sewer lines next to and around their football stadium due to sewer water escaping and penetrating through an embankment onto neighboring property.
Point Design Group was hired by the Upper Tyrone Township Sewage Authority to design a new sanitary system for 602 residents which had failing private on-lot systems.
Point Design Group performed the surveying and design of the 2,700 feet of 12 inch waterline and 100 feet of 8 inch waterline.
Point Design Group was hired by the City of Canton to design the bank stabilization and 72″ sanitary sewer replacement for an area where the bank was slipping towards the creek.
Point Design Group is the engineer for the Village of Lakemore and was hired to design a replacement 6 inch waterline approximately 890 feet long along Martha Avenue in the Village of Lakemore.
